The ultimate thermal interfaces for power electronics
High-performance thermal interface materials formulated and manufactured by Magna-Power specifically for use with power semiconductors.
Pitel Paste Formula AZ-01
| Product Type | Thermal Compound / Grease |
| Base | Aluminum Zinc |
| Conductivity | Non-Conductive |
| Thermal Performance | High |
| Package Types | Container, Tube, or Syringe |
Description
Pitel Paste AZ-01 is Magna-Power’s signature thermal paste formula, designed to satisfy the majority of semiconductor thermal interface requirements for power electronics manufacturers. AZ-01 finds the perfect balance among long-term thermal resistance, viscosity and cost.
Pitel Paste AZ-01 uses a mixture of high-concentration powderized aluminum and zinc oxide suspended in non-conducting silicone oil. This thermal paste formulation was designed specifically for power electronics applications, filling microscopic voids between semiconductors and heatsinks, resulting in a better thermal transfer and ultimately, improved performance capabilities. AZ-01, refined and validated over 8 years by Magna-Power, has a proven track record for delivering superior thermal performance in some of the most demanding power electronics applications.
A wide range of deposition methods are supported for a variety of production needs, including manual deposition, automated dispensing, pneumatic dispensing, and stencil printing.
Pitel Paste is manufactured in the USA at Magna-Power’s manufacturing facility and is compliant with both REACH and RoHS directives.
Packaging
The available packaging and bundling for Pitel Paste Formula AZ-01.
| Package Type | Package Description | Volume |
|---|---|---|
| A | Resealable Container | 236 ml (8 oz) |
| A | Resealable Container | 473 ml (16 oz) |
| A | Resealable Container | 19,000 ml (642.47 oz) |
| B | Tube | 325 ml (11 oz) |
| B | Tube | 946 ml (32 oz) |
| C | Luer Lock Syringe | 1 ml (0.03 oz) |
| C | Luer Lock Syringe | 5 ml (0.17 oz) |
Documentation and Downloads
Safety Data Sheet (SDS)
Datasheet
Thermal Paste Spatula 3D Printing Files
Product Specifications
The specifications for Pitel Paste Formula AZ-01.
| Specification | Value | Testing Method |
|---|---|---|
| Color | Silver Gray | N/A |
| Density | 2.32 g/mL | ATM D70 |
| Viscosity at 10 RPM (T-SP-2) | 80,000 - 110,000 mPa·s | ASTM D2196 |
| Shearing Tendency | Shear thinning | ASTM D2196 |
| Service Temperature | -20°C to 200°C | N/A |
| Storage Temperature (Long-term) |
-25°C to 30°C | N/A |
| Color | Silver Gray | N/A |
| Dispersion Stability | Slight oil separation may occur | ISO/TR 13097:2013 |
| Thermal Conductivity | 2.7 W/m·K | ASTM D7984 |
| Thermal Contact Resistance (40 psi, 25°C) |
6.5 x 10-6 K·m2/W | ASTM D5470 |
| Absolute Thermal Resistance (40 psi, 25°C) |
0.008 K/W | ASTM D5470 |
| Breakdown Voltage | 2.0 kV/mm | ASTM D149 |
| Minimum Bond Line Thickness (40 psi) | 25 µm | N/A |
| Volatile Content | 0.008% | ASTM D2369 |
| Volume Resistivity | 1.2 x 1014 Ohm·cm | ASTM D257 |
| Dielectric Constant | 24.08 @ 1 kHz 23.87 @ 10 kHz |
ASTM D150 |
| Dissipative Factor | 0.01237 @ 1 kHz 0.00390 @ 10 kHz |
ASTM D150 |
